Form controls grouping disappeared after saving

Form controls grouping disappeared after saving

Posted by: yyoshimura on 15 February 2026, 11:38 pm EST

•

  yyoshimura

  • Post Options:
  • Link
    Copy

  Posted 15 February 2026, 11:38 pm EST

  Hi,

  We have a workbook with some form controls grouping together and when saved using the library, the grouping disappeared entirely. If we ungroup the form controls and save again, the form controls remain but format like border lines, filling setting are reset to none. Please see attachment for reproduction. We are using radio options in the test file but other controls have the same problems.

  Please help to resolve this issue. Thank you.

  Regards

  GcExcelTest.zip

•

  chirag.gupta



  • Post Options:
  • Link
    Copy

  Posted 16 February 2026, 2:06 am EST

  Hi Yukinori,

  Apologies for the inconvenience caused.

  We can replicate both reported behaviors on our end.

  Regarding the loss of grouped form controls, support for this scenario is already in our product backlog. However, there is no confirmed ETA at this time. This is tracked under ID DSX-6246.

  Regarding the loss of form control styles during export, this is a current product limitation. As documented, exporting rich text and styles from DsExcel form controls is not supported. This enhancement request is tracked under ID DSX-13933.

  Kind Regards,

  Chirag

  References:

  1. Form Control Limitations: https://developer.mescius.com/document-solutions/dot-net-excel-api/docs/online/Features/excel-form-controls#limitations
•

  chirag.gupta



  • Post Options:
  • Link
    Copy

  Posted 30 March 2026, 2:50 am EST

  Hi Yukinori,

  Thank you for your patience while we coordinated with our development team.

  The issue related to the loss of form control styles has been resolved in DsExcel v9.0.4. Form controls will now retain their styles correctly during export.

  Regarding the grouping of form controls, this feature is currently under development and is planned to be available in DsExcel v9.2.0.

  Please feel free to reach out if you encounter any further issues or need additional assistance.

  Kind regards,

  Chirag
