  Hi,

  I noticed that it is possible to reference a TableSheet’s data array in a formula using the syntax =T[#Data], but =T[#Headers] does not work. How can I retrieve the array of column names within a formula?

  Best Regards

•

  chirag.gupta



  • Post Options:
  • Link
    Copy

  Posted 29 December 2025, 8:12 am EST - Updated 29 December 2025, 8:17 am EST

  Hi Jean,

  We can replicate that in the current SpreadJS implementation; TableSheet only exposes the data region to the formula engine (for example, TableSheetName[#Data]). The column headers (captions) are treated as schema metadata, and accessing them results in the #REF! error, which is why TableSheetName[#Headers] does not work.

  There is no built-in formula syntax to directly return all TableSheet column names.

  As a workaround, this can be achieved by:

  • Retrieving the TableSheet column captions via the TableSheet API in JavaScript and writing them into a helper range or named range, or
  • Defining a custom formula function that takes the TableSheet name and returns the column captions as a dynamic array.

  Please refer to the code sample below that demonstrates how to retrieve the column names from the TableSheet using a custom function.

  We’ve also shared this feedback with our development team for any enhancement considerations under the internal tracking ID SJS-33181.

  Kind Regards,

  Chirag

  Attachment: https://jscodemine.mescius.io/share/ieviIEk1bk67wq1Rt7tq0w

  Working:



•

  chirag.gupta



  • Post Options:
  • Link
    Copy

  Posted 30 December 2025, 7:44 am EST

  Hi Jean,

  The structure of TableSheet headers is not fixed and can vary based on the configuration. You can see this behavior across different scenarios in the following demos:

  1. Column Header Fit Mode: https://developer.mescius.com/spreadjs/demos/features/table-sheet/customize-view/column-header-fit-mode/purejs
  2. Multiple Headers: https://developer.mescius.com/spreadjs/demos/features/table-sheet/multiple-header/purejs
  3. Free Header Area: https://developer.mescius.com/spreadjs/demos/features/table-sheet/free-header-area/purejs

  In contrast, a worksheet table follows a structured reference model with a fixed schema. If you need to retrieve headers from a DataManager table, you can bind the table to a worksheet and directly use the formula: =tableName[#Headers].

  Please refer to the following demo for details on table binding and header access: https://developer.mescius.com/spreadjs/demos/features/tables/table-binding/data-manager-binding/purejs

  If you specifically need to work with TableSheet headers only, please share a detailed user story explaining the requirement that cannot be addressed using the approaches described above.

  Kind Regards,

  Chirag
