Using Visual Studio Code

Visual Studio Code (VS Code) allows you to create ASP.NET MVC application on Windows and Mac systems. To use C1 MVC controls, few additional steps are required to configure the project created using the Visual Studio Code IDE.

  1. Create a new folder on your system for the ASP.NET Core MVC application.

  2. Open VS Code and select File | Open Folder... to open the recently created folder in VS Code.

  3. Select View | Terminal to open the terminal.

  4. In the Terminal, type the following command line to create a new ASP.NET Core MVC application and press Enter.

    dotnet new mvc


    This creates the complete MVC folder structure inside your application folder that you created at the beginning.

  5. To add the ASP.NET Core MVC references to the project, press Ctrl + Shift + P keys and select NuGet Package Manager: Add Package option.

    Note: NuGet package Manager extension is a prerequisite in VS Code for installing NuGet packages.

  6. Type and search for C1.AspNetCore.Mvc package name, select the version and press Enter. The package gets installed.


  7. To use specific controls in your application, add the following NuGet Packages based on the control.

    Control

    NuGet Package

    Financial Chart

    C1.AspNetCore.Mvc.Finance

    FlexSheet

    auto C1.AspNetCore.Mvc.FlexSheet

    OLAP

    auto C1.AspNetCore.Mvc.Olap

    MultiRow

    auto C1.AspNetCore.Mvc.MultiRow

    FlexViewer

    C1.AspNetCore.Mvc.FlexViewer


  8. From the Explorer, expand the folder Views and double click the _ViewImports.cshtml file to open it.

  9. In the _ViewImports.cshtml file, add the following code.

    @addTagHelper *, C1.AspNetCore.Mvc

  10. (Optional) To add specific controls in your application, you need to add the following TagHelpers in the _ViewImports.cshtml file.

| **Control** | **TagHelper** |
| --- | --- |
| Financial Chart |   ``` @addTagHelper *, C1.AspNetCore.Mvc.Finance ```   |
| FlexSheet |   ``` @addTagHelper *, C1.AspNetCore.Mvc.FlexSheet ```   |
| OLAP |   ``` @addTagHelper *, C1.AspNetCore.Mvc.Olap ```   |
| MultiRow |   ``` @addTagHelper *, C1.AspNetCore.Mvc.MultiRow ```   |
| FlexViewer |   ``` @addTagHelper *, C1.AspNetCore.Mvc.FlexViewer ```   |

  1. To add a license, right-click the solution name from the Solution Explorer or go to the Tools menu, and then select MESCIUS License Manager. Optionally, you can also generate runtime license key and add it to your application. For more information on generating license, see Licensing topic.

  2. After completing the steps above, register the resources for the controls to be used in the application.
